AGGLOMERATION MACHINE (DENSIFIER) USED FOR PP/PE RIGID AND FILM
WASHING LINES
Plastic recycling is the processing of making re-useable plastic
raw material from plastic wastes. The process starts with sorting
of the mixed plastics. Clean plastics are crushed and granulated.
Wasted plastics coming from landfills should be crushed, washed,
and dried before granulating line.
AGGLOMERATION MACHINE (DENSIFIER) USED FOR PP/PE RIGID AND FILM
WASHING LINES are used for separating the plastics from contaminants. Efficiency
of washing line directly affects the operation granulating line. An
efficient washing line increase quality of granules and capacity of
granulating line. Washing lines consist of Conveyor, Granulator,
Sin-Float Tanks, Horizontal Centrifuges, Film Dewatering Machine
and vertical Centrifuges in order.
Rigid and film washing lines are used for recycling Polyethylene
(LLDPE, LDPE,HDPE) and Polypropylene (PP) scraps plastics in rigid
or film form. Varity of scrap plastics and can be recycled on the
line is maximized with ability of recycling film and rigid forms
one the same line.
Agglomeration machine are used for drying washed and dewatered
plastics to make them dry and ready for extrusion. Material is
dried by frication occurred between rotating and fixed blades. They
can also be used for size reduction and densification of clean
plastics before extrusion.
The volume of agglomeration container of 300-800 liters are
available according to capacity. They can made of SUS304 stainless
steel.
Improving housing design allows easy bearing and belt change. Power
transfer is realistic under safety cover.
Blades are made of SKD11 material and hardened by heat treatment.
The finished material discharging is opened pneumatically.
The complete crushing, washing and drying line for wasted PP, PE
consist of:
- Belt conveyor
- Horizontal centrifuge: It can applied to maximum cleaning with high
centrifuges.
- Screw conveyor
- Plastic washing units sink (float tank)
- Film dewatering machine
The processing procedure of the complete washing line consists of:
Conveying – Crushing - Floating washer with cold water - Agitating
washer with hot water - Floating washer with cold water -
Centrifugal drying/Squeezing drying – Collection.
- Wasted plastics can be crushed, washed, dried and collected into
silo.
- High efficiency and performance.
- Less power consumption and operator attendance.
APPLICATIONS:
- Applicable material: PP, HDPE, LDPE, LLDPE,, etc..
- Materials shape: woven bag, printed films, agricultural film,
raffia and rigid scraps.
PRODUCTION CAPACITY:
- The production capacity can be 300kg/hr, 500kg/hr,1000kg/hr.
- NOTE: Depending on material shape, some units involved in complete
line will be changed and available.
